• Motorised Valve Actuator-Smart irrigation system

Motorised Valve Actuator-Smart irrigation system

Short Description:

The 4G Motorized Valve Actuator with Solar Power Battery utilizes a motorized mechanism combined with a solar power battery for efficient and sustainable operation. With its 4G connectivity, it allows remote access and control, enabling users to monitor and adjust valve settings from anywhere.


  • Pipe Size: DN150/200/250/300/400
  • Working Power: Solar Battery
  • Flow Meter: External RS485 flow sensor supported
    • facebookissss
    • YouTube-Emblem-2048x1152
    • Linkedin SAFC Oct 21

    Product Detail

    Product Tags

    Our solar battery-operated 4G butterfly valve actuator—an innovative solution for efficient and sustainable valve control. Powered by renewable solar energy, it eliminates the need for external power or wiring. With seamless integration and reliable performance, it ensures optimal valve operation while reducing carbon footprint. Upgrade your system with this cutting-edge actuator, designed for remote and environmentally conscious applications.   Main Features: - Solar powered: It is powered by a built-in solar battery, eliminating the need for external power sources.   - 4G connectivity: It supports 4G mobile network connectivity for remote monitoring and control.   - Butterfly valve operation: Specifically designed for operating butterfly valves, providing precise control and adjustment.   - Wireless communication: Enables wireless communication between the actuator and a control system or monitoring device.   - Automation and control: Allows for automated and remote control of the valve, reducing the need for manual intervention.   - Energy efficiency: The solar battery ensures efficient energy usage, making it an environmentally friendly option.

    Mode No. MTQ-100-G
    Power Supply DC12/24V 3A
    Battery : 6000mAH
    Solar Panel:polysilicon 6V 5.5W
    Consumption Data Transmit:3.8W
    Block:25W
    working Current: 65mA,sleep:10μA
    Network 4G cellular Network
    Valve Torque 100~1000Nm
    IP Rated IP67
    Working Temperature Enviroment Temp: -30~65℃
    Water Temp:0~70℃
    Available ball Valve Size DN150~400
